GJYXHA
Cytech
Product Description
GJYXHA Armored Fiber Drop Cable is a compact, flexible, and flame-retardant cable designed for indoor Fiber-to-the-Home (FTTH) installations. It features tight-buffered fibers and aramid yarn reinforcement, ensuring easy deployment, durability, and reliable high-speed connectivity in residential or building settings.
•Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property;
•Strong strength members ensure good performance of crush resistance to protect the fiber;
•Simple structure,light weight and high practicability;
•Novel flute design,easily strip and splice,simplify the installation and maintenance;
•Low smoke,zero halogen and flame retardant sheath;
Applications: Access network, fiber to the home(FTTH);
Laying method:Indoor integrated wiring;
Working temperature:-20℃~+60℃；
Bend Radius: Static 20mm,
Dynamic:40mm.
YD/T 1997.1-2022 Drop optical fibre cables for telecommunication Part1:Bow-type optical fibre cables
Fiber count | Cable Diameter(mm) | Cable Weight(KG/KM) | Max.tensile strength(N) | Max.Crush resistance(N/100m) | ||
Short Term | Long Term | Short Term | Long Term | |||
1 | 6.2 | 25 | ≥600 | ≥300 | ≥2200 | ≥1000 |
2 | 6.2 | 25 | ≥600 | ≥300 | ≥2200 | ≥1000 |
4 | 6.2 | 25 | ≥600 | ≥300 | ≥2200 | ≥1000 |
GJYXHA-G.657A1 Armored Fiber Drop Cable.pdf
(1) When laying the Armored fiber drop cable, it should be kept straight, avoiding twisting and crossing, and should not be subjected to external compression or operational damage.
(2) At corners or bends, the Armored fiber drop cable should have a certain curvature to ensure its bending radius, and be protected with sleeves or other protective measures to prevent the cable from being damaged.
(3) The laying of Armored fiber drop cable should fully consider safety requirements such as fire prevention, rodent prevention, and compression prevention to ensure the long-term stable operation of the cables.
(4) For important users or scenarios with special requirements, appropriate protection methods should be selected according to the actual situation to enhance the reliability and safety of the Armored fiber drop cable.
(5) During the laying process of Armored fiber drop cable, professional cable laying tools and brackets should be used to avoid entanglement or unnecessary tension on the cables. At the same time, attention should be paid to the tensile strength and bending radius of the cables.
(1) Regular preventive maintenance should be carried out to check whether the outer skin, joints, and connectors of the Armored fiber drop cable are intact, and whether there are signs of wear, aging, or damage. Problems should be detected and dealt with in a timely manner to prevent small problems from escalating into major failures.
(2) Establish maintenance records, detailing the time, content, results, etc. of each maintenance to facilitate subsequent analysis and optimization of maintenance strategies.
(3) During the maintenance process, professional techniques and tools should be used to avoid non professionals operating on their own, ensuring the safety and effectiveness of the maintenance work.
(4) According to the environmental conditions of the Armored fiber drop cable, corresponding maintenance measures should be taken, such as strengthening inspections, moisture prevention, dust prevention, etc., to ensure the long-term stable operation of the optical cable.
Armored fiber drop cables are extensively used in outdoor settings, such as along highways, railways, and power lines, where they are exposed to harsh weather conditions and physical stresses.
In industrial zones, these cables are employed to connect various facilities and equipment, ensuring reliable communication in environments with high levels of electromagnetic interference and mechanical risks.
Due to their robustness, armored fiber drop cables are ideal for military applications, providing secure and durable communication links in field operations and permanent installations.
They are also used in urban areas for last-mile connectivity, delivering high-speed internet and other services directly to homes and businesses.
The armored layer provides superior protection against physical damage, such as crushing, rodent bites, and environmental hazards, ensuring long-term reliability.
The robust construction makes it difficult to tap or damage the cable, offering enhanced security for sensitive data transmission.
Despite their strength, these cables maintain a degree of flexibility, allowing for easier installation in complex and varied terrains.
They are designed to withstand extreme temperatures, moisture, and UV exposure, making them suitable for a wide range of outdoor applications.
Due to their durable construction, armored fiber drop cables require less maintenance over their lifespan, reducing overall operational costs.
They support high-speed data transmission, meeting the demands of modern communication networks for large volumes of data.
Packaging Details: Packed on drums;
Drums length: 1KM,2KM, 3KM or 4KM, as per buyers’ request
Delivery detail: 15 days
